Loma X5 Compact X-ray Inspection System


The X-ray Inspection Solution with the Smallest Footprint

Why Choose the Loma X5 Compact X-ray Inspection System

integration icon 2

Ideal for detecting contaminants inside metallised packaging, calcified bone fragments, dense rubber, stones, and glass.



target icon

Effortless to use and integrate, the Loma X5 Compact X-ray inspection system is the perfect choice for businesses introducing X-ray technology for the first time.

integration icon

The IP55 protection rating and advanced technical standards ensure long-term durability and consistent performance even during continuous operation.

Technical Information

Frame AISI 304 Stainless Steel
Production Line Height 900 mm ± 50 mm (other sizes available on request)
System Length 1,000 mm
Inspection Width 300 mm
Maximum Load Capacity 9 kg
Power Supply 230 / 1 ph / 50 Hz or 110 / 1 ph / 60 Hz N+E
Compressed Air from 5 to 8 bar
Reject Types signal only
Dust/Moisture Protection Level IP55 standard
Belt Types foodgrade conveyor
Included in Supply quick-release belt – contaminant detection – volume check – product absence – saving captured images to USB – fixed speed
Optional Features Reject confirmation, Full bin alert, X-ray sensor, Remote support, LomaEnet
X-ray Detection Latest-generation detector with 0.8 mm diode ensures optimum performance at all times
Industrial PC Equipped with Windows embedded operating system
WASC Cooling System (Wide Angle, Self Cooled) Digitally regulated for stable X-ray tube operation. (Tube lifetime estimated at 10,000 hours)
Password-Protected Access yes
Reporting and Image Storage via USB or Ethernet yes
Advanced Diagnostics with Event Logging yes
Information Dashboard system usage displayed on monitor (operating hours, power-on time, etc.)
Reject Signal Management 2 outputs for contaminant detection and product defects
