Loma X5 800 XL X-ray Inspection System


The X-ray Solution for Inspecting Bulky Food Products

Why Choose the Loma X5 800 XL X-ray Inspection System

target icon

Designed to handle large sealed bulk goods prior to processing or shipment. Perfect for oversized crates of meat or cheese wheels.

environment icon

The Loma Series 800 XL X-ray system includes a new X-ray source (18W Eco Mode) that minimizes environmental impact and energy consumption.

Technical Information

System Length 2,500 mm
Inspection Width 800 mm
Maximum Conveyable Weight 100 kg
Power Supply 230 / 1 ph / 50 Hz or 110 / 1 ph / 60 Hz N+E
Compressed Air from 5 to 8 bar
Ejector Types signal only
Dust/Moisture Protection Rating IP66 standard, NEMA 4X
Belt Types Modular Intralox foodgrade
Included Functions contaminant detection – volume, shape, and size control – missing product check – image archiving – variable speed
Options reject confirmation, full bin, X-ray detector, remote support, Loma Tracs2, multi-lane inspection
AAT Technology (Adaptive Array Technology) enables selection of inspection diode size (0.4 – 0.8 – 1.6 mm) for optimal performance at all times
Industrial PC with Windows operating system
WASC Cooling System (Wide Angle, Self Cooled) digitally controlled for consistent X-ray tube performance (tube life estimated at 7 to 10 years)
Password-Protected Access yes
Reports & Image Saving via USB or Ethernet yes
Advanced Diagnostic System with Event Logging yes
Information Dashboard system usage monitoring (operating hours, on-time, etc)
Ejection Signal Management multiple causes (e.g., contaminants detected, product defects, etc.)

The Loma X5 800 XL X-ray system is specifically designed for the food industry, built from AISI 304 stainless steel, making it easy to clean and sanitize. All materials are suitable for direct food contact, and the system can inspect up to 360 cheese wheels per hour.
