Loma IQ4H Lock-PH Pharmaceutical Metal Detector System


Pharmaceutical Metal Detector for Tablets with Integrated Ejection

The Loma IQ4H Lock-PH pharmaceutical metal detector system is engineered for the detection of metallic contaminants in pharmaceutical manufacturing, featuring a dedicated reject mechanism for metallic fragments and capable of processing up to 30,000 tablets per minute.

Utilizing specialized, rapid and precise ejection devices, it ensures reliable rejection of non-compliant products, preventing unnecessary waste. The Fail Safe mode guarantees proper reject management in the event of power failure.

The Loma IQ4H Lock-PH metal detector has been designed to deliver consistent performance even in environments with vibration, ensuring stable product signal readings.

Why Choose the Loma IQ4H Lock-PH Pharmaceutical Metal Detector

icona raggiungimento obbiettivi

Easy Installation whether on a stand or not, and with auto-setup simplifies operation and maintenance thanks to quick-release parts.

icona integrazione

Stainless steel housing offers IP66 protection rating.

icona rispetto normativ

Supplied with IQ/OQ/PQ validation documents. Fully meets CFR21 part 210 and 211 compliance requirements.

Technical Information

Housing Polished AISI 304 stainless steel, with assisted height adjustment
Reject Mechanisms 12 available models, with components manufactured in AISI 316
Head Opening Head opening 95×22 mm, 95×38 mm
User Interface 7’’ touchscreen monitor
Power Supply 110-250 V AC 50/60 Hz Power consumption 20 VA
Operating Temperature -10ºC to +35ºC
Operating Relative Humidity 0 to 95% non-condensing
Dust/Moisture Protection Rating IP66
Direct Digital Signal (DDS) Enables vector visualization of head operation to optimally support operator activity
Reinforced Structure Delivers maximum signal stability in demanding operating conditions
Assisted Height Adjustment with Pneumatic Cylinder Yes
Single Working Frequency Up to 1 MHz
Product Auto-Setup Yes
Connectivity USB for downloading production data. Ethernet for Tracs 2 software connection or protocol communication
Continuous Self-Diagnosis of Inspection Head Yes
Validation Documents IQ/OQ/PQ
Regulatory Compliance CFR21 part 10 and 11 when used with Tracs 2 software
Optional Tracs 2 Data Collection Software Analysis, reporting, and batch trend monitoring. Remote system parameter configuration. Data exportable (CSV) and printable. Secure, unalterable internal database
