Brother TD‑4520TN


Efficient and durable label & barcode printing

The Brother TD‑4520TN is a compact, professional label printer combining high print quality with robust performance. With a resolution of 300 dpi and both thermal transfer and direct thermal modes, it produces sharp, long-lasting labels up to 112 mm wide (max usable width 105.7 mm).

Featuring a print speed up to 127 mm/sec (5 ips), it minimizes waiting time and increases productivity. Seamless integration is provided via standard ports: USB 2.0, Ethernet LAN (10/100 Mbps), and RS‑232 serial. It ships with free Seagull BarTender UltraLite label software included.

Supports printing on pallets, boxes, cardboard, glass, plastic, and metal, and is compatible with a wide range of 1D and 2D barcode standards.

Why choose Brother TD‑4520TN


High­-resolution printing
300 dpi ensures crisp text and barcode clarity.


Versatile media handling
Compatible with pallets, cardboard, plastic, metal, glass.


Multiple connectivity options
USB, Ethernet and RS‑232; compatible with ZPL/ZPL2, EPL, DPL.

Technical specifications

Printing technology Thermal transfer / Direct thermal
Resolution 300 dpi (12 dots/mm)
Max print width 105.7 mm (usable up to 112 mm)
Max print speed 127 mm/sec (5 ips)
Max media width 112 mm
Max print length 11,430 mm (450 in)
Supported barcode types Linear: Code128, EAN‑8/13, ITF‑14, Code39, MSI, POSTNET, LOGMARS; 2D: PDF417, DataMatrix, QR Code, Aztec, GS1 DataMatrix etc.
Connectivity USB 2.0, USB host, Ethernet LAN, RS‑232C serial
Memory 64 MB SDRAM, 128 MB flash
Software Seagull BarTender UltraLite included
Dimensions (WxDxH) 204 × 280 × 177.5 mm
Weight 2.5 kg
Operating temp./humidity 5 °C to 40 °C / 25–85% RH (non‑condensing)
